Artromot E2 Elbow CPM

Artromot E2 Compact Elbow CPM provides anatomical motion for the elbow and enhances patient comfort and compliance. The Artromot Elbow CPM addresses full range of motion capabilities - Pronation/ Supination and Flexion/Extension.  The use of this product is strictly reserved for health professionals.

The Fleece Patient Kit for the Artomot E2 Elbow Continuous Passive Motion Machine is made of high quality sheepskin, fleece, and soft foam. The comfortable fleece kit was crafted to fit with the Artomot E2 Elbow Continuous Passive Motion Machine. (Patient kit sold separately)

Features & Benefits:

• Fully synchronized motors allow treatment parameters to be customized to meet patient's specific therapy protocols
• Easy-to-use hand control capable of storing treatment data on memory chip card
• True physiological movements with the greatest range of motion
• Anatomically correct adjustments
• Easy to transport
• Lightweight 35 lbs (16 kg)
• Two-year limited warranty

Technical Specs:

Exension/Flexion	-5 - 140°
Pronation/Supination (manual setup)	-90 - 90°
Motor Control	On/Off
Pauses	0 - 30 seconds
Speed	0 - 100%
Speed	0 - 100%
Timer	1 - 300 minutes
Warm-Up Mode	50% of Programmed ROM
Synchronization	On/Off
Reverse-On-Load	1 - 25
Therapy Run Time	h : m
Display Contrast	n/a
New Patient Data Storage	n/a
Unit Weight	35.2 lb (16 kg)
Shipping Weight	54 lb (24.5 kg)
Dimensions	30.7" - 40.9" x 23.6" x 31.5" (84 - 104 cm x 60 cm x 80 cm)
Safety Tests	CSA - 601-0-M90, UL - 2601-1
