Key Features

• OneTouch WheelBase® System
• Power hi-lo and manual backrest
• One-function foot control with hi-lo
• Single column electro-magnetic actuator
• 18”-21” paper roll holder (53.3cm)
• 500lb (226.8kg) patient weight capacity
• ADA Accessible 19” (48.3 cm)
• Large front drawer
• Drain pan: plastic 1.5’ deep (3.81cm)
• Removable, seamless upholstered top with PreFixx® Protective Finish
• Heavy-gauge steel extension leg pull-out to accommodate most patient heights
• Stirrups with four lateral positions, adjustable length
• Durable, steel construction
• Easy-clean powder coat enamel surfaces
• 3-year limited warranty

Specifications

• Height: min. 19” (48.3 cm) at seat max. 32” (81.3 cm)
• Width: 28” (71.12 cm)
• Length: 58”-76” with foot section extended (147.3 cm – 193.0 cm)
• Leg rest: 18” W x 18” D (45.7 cm W x 45.7 cm D)
• Storage Drawer (Front): 18.0” W x 12.0” D x 3.0” H (46 cm x 30 cm x 8 cm)
• Single column electro-magnetic actuator
• International model: 3002-01
• Electrical: 120-240 VAC, 50-60 HZ
• Weight capacity: 500lb (226.8kg)
• Net weight: 300lb (136kg)
• Shipping weight: 350lb (159kg)
• Shipping dimensions: 30” W x 64” L x 31” H (76 cm x 163 cm x 79 cm)

ACCESSORIES - SEARCH THE BELOW ITEM NUMBERS & ADD TO CART:

• 047-251 – Bierhoff Knee Crutches (pair)
• 047-581 – Hand Control
• 047-585 – Armrests
• 047-590 – Welch Allyn Light Bracket capabilities for #48955 (patient left)
• 047-591 – Welch Allyn Light Bracket capabilities for #48955 (patient right)
